●Product Parameters
| MODEL | MIG-2500 |
| Rated Input Voltage(V) | 1P 220V土10% |
| Frequency (Hz) | 50/60 |
| Rated Input Capacity (KVA) | 7.2 |
| Rated Output(AV) | MIG:193/23.6 MMA:174/26.9 |
| No-Load Voltage(V) | 65 |
| Adjustable Current Range(A) | 20-250 |
| Duty Cycle (%) | 40 |
| Efficiency(%) | 85 |
| Wire Feeder | built in |
| Wire Diameter (MM) | 0.8-1.0 |
| Spool Size(KG) | 1/5 |
| Net Weight(KG) | 11 |
| Machine Dimension(MM) | 420x255x330 |
●Ambient temperature range
The KEYGREE MIG-2500 WELDER is designed for use by the serious hobbyist or the busy professional with the versatility to MIG, Stick or Lift TIG weld all from a single compact, space-saving and lightweight unit combined with self-sensing, dual-voltage capability for go anywhere convenience. The latest IGBT inverter technology produces the most stable arc possible and provides the capability of welding thin or heavy gauge steel with precision and ease. A powerful, 200 amp maximum welding output allows welding up to 5/32'' thick steel and a unique, built-in Spot Weld Timer feature allows for exact, factory perfect spot welds on automotive restoration projects.
DUTY CYCLE
The rated Duty cycle refers to the amount of welding that can be done within an amount of time. The
KEYGREE MIG-2500 has a duty cycle of 60% at 200 Amps for 220 Volts. It is easiest to look at your welding time in blocks of 10 Minutes and the Duty Cycle being a percentage of that 10 Minutes. If welding at 250 Amps with a 60% Duty Cycle, within a 10 Minute block of time you can weld for 6 Minutes with 4 Minutes of cooling for the Welder.
●MIG-2500 has the following advantages
(1) The hydrogen content in welding is less, so the ability of welding low-alloy high-strength steel to resist cold cracks is improved
(2) When the droplet adopts short-circuit transition, it can be used for vertical welding, overhead welding and all-position welding
(3) The arc has good visibility, which is conducive to observation, and the welding wire can be accurately aligned with the welding line, especially in semi-automatic welding, which can easily realize the welding of short welds and curved welds
