● Product Parameters
| Model | MIG-165 | MIG-185 | MIG-205 | MIG-205K | MIG-250K | ||
| Rated Input Voltage | 1P 220V | 220V/380V | 220V/380V | ||||
| 220V | 380V | 220V | 380V | ||||
| Rated Input Power(KVA) | 5.6 | 6.6 | 7.5 | 8 | 10 | ||
| Rated Input Current(A) | 26 | 30 | 35 | 34 | 23 | 40 | 23 |
| No-Load Voltage(V) | 52 | 62 | 58 | 62 | 54 | 54 | 54 |
| Rated Output(A/V): MIG | 1 50/21 | 1 80/22 | 200/23 | 200/24 | 250/26 | ||
| Rated Output(A/V): MMA | 1 50/25.6 | 1 80/26.4 | 200/27.2 | 200/28 | 250/30 | ||
| Duty Cycle (%) | 50 | 50 | 60 | 50 | 50 | ||
| Wire Weight(kg) | 1/5 | 1/5 | 5 | 1/5 | 5/15 | ||
| Wire Diameter(mm) | 0.8-1.0 | 0.8-1.0 | 0.8-1.0 | 0.8-1.0 | 0.8-1.2 | ||
| Insulation Class | IP21S | IP21S | IP21S | IP21S | IP21S | ||
| Power Factor | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 | ||
| Efficiency(%) | 80% | 80% | 80% | 80% | 80% | ||
| Machine Dimension (MM) | 425*200*355 | 425*200*355 | 530*310*500 | 425*200* 355 | 490* 245*415 | ||
| Net Weight(KG) | 8.9 | 9 | 11.2 | 9.5 | 15 | ||
● Work Environment.
(1) The environment should be dry and the air humidity didn't exceed 90%.
(2) Temperature should be from-10℃ to 40℃.
(3) Avoid welding under rain or hot sunshine, don't let water or rain into machine.
(5) Avoid using the machine under strong air flow.
(4) Don't work under dust area or aggressive fume.
● Safe tips
The machine is equipped with over voltage, over current and overheat protection device. If the voltage, output current and temperature exceed the standard, the machine will stop working. Besides, overusing the machine based on exceeded voltage, the machine will be damaged，, so please kindly note as below
(1) Ensure Good Airiness.
During the working, the machine will generate high temperature and it needs help from fan to cool the
machine. So users please make sure the ventilation inlet is not stuck or covered. Meanwhile, keep the
objects around the machine in a distance of no less than 0.3m. Keeping airiness helps to lower the
temperature more quickly and ensures a longer service life of the machine.
(2) Current Overloading Prohibited
Close attention should be paid to the permissible loading current(the available duty cycle) to ensure
the welding current being under maximum permissible current. Current overloading shortens service life of a machine greatly, or even damages the machine.
(3) Earth cable connects to the ground. There is a mark near the earth screw on the back panel Before using the machine, please choose a wire (cross sectional area above 6 mm2) to connect the earth screw to ground to avoid electricity leakage accident and release static electricity.
(4) No overload of the standard rated duty cycle. When it overloads the standard, the machine will stop working due to overheat inside of machine. After stopping and resting for some time, the machine can be started to work again.
