● Product Parameters
| MODEL | LY20BS |
| Optical Class | × |
| Cartridge Size | 108×51×5.5mm |
| Viewing Area | 90×34m(3.54"×1.34") |
| Light State | DIN3 |
| Dark State | DIN11.5±1.5 |
| Shade Control | No |
| Switching Time | 3/10000S±20% |
| Sensitivity Control | No |
| Delay Time | 0.2S |
| Power Supply | Li-battery&Solar |
| Rated Capacity Of Li-Battery | 60mAH |
| Replaceable Battery | No |
| Operating Temp. | -5℃～55℃ |
| Storing Temp. | -20℃～70℃ |
| Arc Sensor | 2 |
| Low Amperage TIG Rated | ≥30amps |
| Helmet Material | PP or PA |
| UV/ IR Protection | DIN11 |
| Test | No |
| Low Battery | No |
| Grinding | No |
| Cuting | No |
| LED | No |
