● Product Parameters
| MODEL | TIG-170 | TIG-200 | TIG-250 | TIG-315 | |
| Rated Input Voltage(V) | 1P 220V | 1/2PH 220/380V | 3P 380V | 3P 380V | |
| Input Frequency(Hz) | 50/60 | ||||
| Max Input Current(A) | 20.3 | 25.6 | 10.6 | 13.6 | |
| Rated Input Power(KVA) | 7.8 | 11.1 | 7.1 | 8.5 | |
| No-Load Voltage(V) | 58 | 52 | 52 | 55 | |
| Max Output Current(A) | TIG | 170 | 200 | 250 | 290 |
| MMA | 170 | 200 | 225 | 260 | |
| Adjustable Current Range | TIG | 15-170 | 15-200 | 20-250 | 20-315 |
| MMA | 15-170 | 15-200 | 20-250 | 20-315 | |
| Duty Cycle(%) | 60 | ||||
| Net Weight(KG) | 7.8 | 10.2 | 12.5 | 15.8 | |
| Machine Dimension(MM) | 340*190*330 | 390*200*320 | 430*230*375 | 485*245*420 | |
● The characteristics of argon arc welding are:
1. Wide range of applications, almost all metals can be used for argon arc welding, especially for chemically active metals or alloys, such as stainless steel and aluminum, magnesium, titanium, copper and their alloys.
2. Open arc welding, the heating and melting of the arc and the molten pool and the formation of the weld seam during the welding process are clearly visible, which is convenient for the welder to operate and adjust, and the welding quality is easy to control.
3. Excellent argon protection performance, good arc stability, small spatter, simple welding metallurgical process, and easy to obtain pure and satisfactory welds.
4. The arc heating is concentrated, the heat-affected zone is narrow, the welding stress and deformation are relatively small, and it is suitable for thin plate welding.
