● Product Parameters
| Position | Code | Ref. | Description |
| 1 | KVS0071 | Nozzle/ceramic/PT31 | |
| 2 | KVU0880-08 | Tip 0.8/IMT35/HAND | |
| 3 | KVU0086 | Tip/PT31 30A | |
| 4 | KVF0663 | Diffuser IMT35 | |
| 5 | KVF0078 | Diffuser/PT31 | |
| 6 | KVB0710 | Electrode IMT35 | |
| 7 | KVB0087 | Electrode/PT31 | |
| 8 | KFT0980 | "O" RING Φ12.5*2.5MM RED SILICON/HS60 | |
| 9 | KVZ0710 | Plasma Cutting Torch Head IMT35 | |
| 10 | KGV0025 | Plasma handle PT31 | |
| 11 | KHQ0240 | Switch kit/SG51/SG55/P31 | |
| 12 | KHJ0860 | Small joint TIG 9-17-20 | |
| 13 | KHJ0868 | Big spring support | |
| 14 | KVN02104045-98 | Cable assembely/IMT35/4MMQ/4M/M16×1.5/E | |
| 15 | KHJ0029 | Protection nut CH19 | |
| 16 | KHQ0757 | Conntector 2 holes |
● Complete Torch
| Code | Ref. | Description |
| KVT02251 | Plasma Torch IMT35/4M/M16×1.5 |
