● Product Parameters
| Model | TIG-205P ACDC | |
| Rated Input Voltage(VAC) | 1P 220V | |
| Input Frequency(Hz) | 50/60 | |
| Max Input Current(A) | 37 | |
| Rated Input Power(KVA) | 9.2 | |
| No-Load Voltage(V) | 56 | |
| Real Output Current(A) | TIG | 205 |
| MMA | 180 | |
| Adjustable Current Range(A) | TIG | 10-205 |
| MMA | 20-180 | |
| Duty Cycle(%) | 40 | |
| Gas Regulation | Pre -Gas（S） | 0.1-5 |
| Post-Gas（S） | 0.5-15 | |
| Current | Start | 10%-100% |
| Stop | 10%-100% | |
| Slope Up（S） | 0-10S | |
| Slope Down（S） | 0-15S | |
| Pulse | Frequency（Hz） | 0.2-200Hz |
| Balance(%) | 0.2-9.9Hz 1%-99% 10-200hz 10%-90% |
|
| Cold Welding Time（MS） | 0.1-10 | |
| Machine Weight(KG) | 9 | |
| Machine Dimension(MM) | 450*195*350 | |
