● Product Parameters
| Model | RSN-2500X | RSN-2500 | RSN-3150 |
| Input Power Source | 3P 380V | ||
| Rated Input Capacity | 97KVA | 121KVA | 153KVA |
| Rated input current | 147A | 185A | 214A |
| No-Load Voltage | 90V | 108V | 108V |
| Maximum length of ground cable | 30m | 30m | 30m |
| Duty Cycle | 0.15 | 0.15 | 0.15 |
| Current adjustment range | 300-2000A | ||
| Weldable stud diameter | 6-19mm | ||
| Welding time | 0.3-3 | ||
| Stud length | ≤400 | ||
| Efficiency | 0.9 | ||
| Insulation Class | IP21S | ||
| Dimensions | 690X390X760mm | ||
| Weight | 75KG | ||
