● Product Parameters
| Model | ARC-260 | ARC-290 | ARC-330 | ARC-400 |
| Rated Input Voltage(V) | 3P 380V | 3P 380V | 3P 380V | 3P 380V |
| Rated Input Current(A) | 17.5 | 19.3 | 23 | 30 |
| Input Capacity(KVA) | 11.6 | 12.7 | 15.2 | 20 |
| Inverter frequency | 20 | 20 | 20 | 20 |
| No-Load Voltage(V) | 68 | 68 | 68 | 70V |
| Duty Cycle(%) | 60 | 60 | 60 | 60 |
| Current Range(A) | 40-400 | 40-400 | 40-500 | 40-500 |
| Electorode Diameter(MM) | ≤4.0 | ≤4.0 | ≤5.0 | ≤6.0 |
| Efficiency(%) | 80 | 80 | 80 | 80 |
| Insulation Class | F | F | F | F |
| Real Current(A) | 260 | 285 | 330 | 400 |
| Dimension(MM) | 405*215*390 | 470*235*435 | 515*265*475 | 515*265*475 |
| Weight(KG) | 12.3 | 14.5 | 18.4 | 20 |
